Wiseco
Wiseco 871M08950 Piston Kit - 0.50mm Oversize to 89.42mm, 6.8:1 Compression
Generally ships to addresses in the contiguous United States the same business day if ordered by 12:15PM Central Time!
Bore: 89.42mm
Compression: 6.8:1 Compression
Sizing: 0.50mm Oversize
SPECIFICATIONS.
Displacement: 497cc.
Bore - Standard: 89.00mm.
Bore - Actual: 89.50mm.
Bore - Oversize: .50mm.
Stroke: 79.00mm.
Cylinders: 1.
Compression Ratio - Actual: 6.8:1.
Skirt Coating: ArmorGlide.
ITEM CONTENTS.
3520KD - 3.520 Semi Keystone Ring Set.
CW20 - ROUND WIRE PIN LOCKS 20MM (PAIR).
S512 - PistonPin 20mm x 2.362in. NonChromed TW
All Wiseco Pistons are forged from high silicon, low expansion aluminum which offers superior strength, reduced weight, improved heat transfer, and longer life. Diamond turned finish from one of the many CNC computer controlled turning centers guarantees you a perfect finish with no size variation. Wiseco pistons can be installed in any of todays cylinder bore compositions. Wisecos state-of-the-art computerized manufacturing facility is dedicated to supplying both the high-perfomance racer and recreational enthusiast with the finest forged piston available in todays market place.
1982-1983 Honda CR480R
1984-2001 Honda CR500R
Bore: 89.42mm
Compression: 6.8:1 Compression
Sizing: 0.50mm Oversize
SPECIFICATIONS.
Displacement: 497cc.
Bore - Standard: 89.00mm.
Bore - Actual: 89.50mm.
Bore - Oversize: .50mm.
Stroke: 79.00mm.
Cylinders: 1.
Compression Ratio - Actual: 6.8:1.
Skirt Coating: ArmorGlide.
ITEM CONTENTS.
3520KD - 3.520 Semi Keystone Ring Set.
CW20 - ROUND WIRE PIN LOCKS 20MM (PAIR).
S512 - PistonPin 20mm x 2.362in. NonChromed TW
All Wiseco Pistons are forged from high silicon, low expansion aluminum which offers superior strength, reduced weight, improved heat transfer, and longer life. Diamond turned finish from one of the many CNC computer controlled turning centers guarantees you a perfect finish with no size variation. Wiseco pistons can be installed in any of todays cylinder bore compositions. Wisecos state-of-the-art computerized manufacturing facility is dedicated to supplying both the high-perfomance racer and recreational enthusiast with the finest forged piston available in todays market place.
1982-1983 Honda CR480R
1984-2001 Honda CR500R
Please Note: Ships same business day to contiguous US if ordered by 12:15 PM Central Time!
Note: 871M08950
